ZEPHYR SSL Integrated Handlebar

ZEPHYR SSL Integrated Handlebar

360-80mm
€349,00
Skip to product information
ZEPHYR SSL Integrated Handlebar
  • ZEPHYR SSL Integrated Handlebar
  • Quick Pro Blade Frame Custom Matte Black
  • ZEPHYR SSL Integrated Handlebar
  • ZEPHYR SSL Integrated Handlebar
ZEPHYR SSL Integrated Handlebar

ZEPHYR SSL Integrated Handlebar

One-Piece Cockpit. Zero Compromise.
€349,00
Taxes included.
Handlebar size
1 left
Shipping

We aim to ship your order the same day or the next business day.


Benelux: delivery within 1–2 days after dispatch
Rest of EU: delivery within 5–10 days after dispatch


Fast, reliable shipping — so you can get riding sooner.
Return policy

You have the right to return your order within 14 days of delivery, in accordance with EU consumer protection laws.

To be eligible for a return, the item must be in its original condition and packaging. Returns are not accepted for items that have been installed, assembled, or modified.

Once your return is received and inspected, we will issue a refund to your original payment method.
Warranty

5-year manufacturer warranty on all framesets

Hybrid SSL/T1100
Carbon Construction

The ZEPHYR SSL uses a premium layup of Toray T1100 tensile-grade carbon fiber combined with M65 ultra-high modulus fibers. The result is a handlebar that excels in every dimension — stiff where it needs to be, lightweight where it matters, and resilient against the impacts of real-world racing.

Nano-Resin
Technology

Integrated nano-resin throughout the laminate dramatically increases resistance to micro-cracking and high-load fatigue. The same nanotechnology used in Quick Pro's frame lineup is applied here, meaning the cockpit performs to the same durability standard as the bike it's mounted to.

One-Piece
Integrated Design

The seamless monocoque construction eliminates the stem/bar interface entirely — reducing weight, improving stiffness, and creating a cleaner aerodynamic profile. Full internal cable routing keeps hoses and wires hidden from bar-end to head tube for a professional, drag-minimizing appearance.

Specifications

  • Fully compatible with internal cable routing systems
  • Compatible with standard 28.6mm steerer tubes
  • Integrated computer mount (straight, ~1° angle)
  • Compatible with major bike computer brands including Garmin and Wahoo
  • One-piece monocoque molding for maximum rigidity
  • UCI legal
  • Designed and tested to complement the Quick Pro ER:ONE, UR:ONE, AR:ONE and BLADE frame geometry

Sizing

Ref Specification 340mm 360mm 380mm 400mm 420mm
A Hood-to-hood (mm) 340 360 380 400 420
B Drop-to-drop (mm) 366.5 386.5 406.5 426.5 446.5
C Stem Length (mm) 70-110 80-140 80-140 80-140 90-140
D Flare Angle (°) 6.1° 6.1° 6.1° 6.1° 6.1°
E Stem Angle (°) -8° -8° -8° -8° -8°
F Stack (mm) 37 37 37 37 37
Reach (mm) 75 75 75 75 75
Drop (mm) 125 125 125 125 125

How to choose your size:
Bar width should match your shoulder (bi-acromial) width or go 1cm narrower for an aggressive, aero fit. Measure shoulder-bone to shoulder-bone. If your shoulders measure 39cm, a 380mm bar gives you a locked-in race position. Note: as a one-piece integrated handlebar, stem length cannot be adjusted after purchase — confirm your fit metrics before ordering.

What's included

Frameset includes:

1× ZEPHYR SSL Integrated Handlebar
Stem bolts
Bar end plugs
Computer mount
Installation guide

The ZEPHYR SSL is Quick Pro's flagship integrated handlebar — a UCI-grade, one-piece cockpit engineered for serious road racing. Built from a hybrid layup of Toray T1100 and M65 carbon fibers with nano-resin reinforcement, it delivers the torsional rigidity demanded by sprinters and climbers while remaining light enough to compete at the front of any peloton.

Weighing in at just 288g (380×90mm, including accessories), the ZEPHYR SSL combines a fully internal cable routing system with clean one-piece molding for an aerodynamic, drag-free profile. Whether you're building up a Quick Pro frame from scratch or upgrading an existing cockpit, the ZEPHYR SSL is the definitive finishing touch for a race-ready build.

Related products

Questions? We've Got You Covered!

Is the ZEPHYR SSL compatible with my Quick Pro frame?

Yes. The ZEPHYR SSL is designed to pair with all Quick Pro frames using a 28.6mm steerer and internal cable routing, including the ER:ONE and AR:ONE. If you're unsure about compatibility with another brand's frame, contact us with your headtube spec and we'll confirm.
Can I upgrade the stem length later?

No — this is a one-piece integrated handlebar. The stem reach is fixed at the time of purchase. This is standard for all integrated cockpits. Make sure to confirm your bike fit before ordering.
What is the weight?

288g ±3% for the 380×90mm size, including all accessories and paint. This makes the ZEPHYR SSL one of the lightest production-quality integrated handlebars in its class.
Is the ZEPHYR SSL UCI approved?

Yes, the ZEPHYR SSL meets UCI regulations and is suitable for use in sanctioned road racing events.
Why buy the handlebar separately instead of as part of the frame package?

Many riders order frames with a different cockpit already owned, or prefer to spec their own fit. Offering the ZEPHYR SSL separately means you can add it at any time — whether completing a new build, replacing a damaged cockpit, or upgrading a previous bike.
